Physical Design
Acquire industry relevant skills in Physical Design and gain hands-on
project experience with tools like ICC and Fusion-Compiler, ensuring
you are job-ready in the thriving semiconductor field.
Our Physical Design Course offers a comprehensive understanding of VLSI design flows, focusing on synthesis and optimization to achieve improved power, performance, and area (PPA). You’ll gain in-depth knowledge of static timing analysis (STA) from synthesis through to physical design signoff, as well as the complete physical design process from floorplanning to post-route. The course includes practical exposure to industry tools, along with valuable experience in real-world challenges through demo projects. You'll also learn scripting with Shell and TCL to enhance efficiency. With access to online study materials and library facilities, you’ll receive placement assistance and mock interview preparation under the guidance of industry experts, ensuring you are well-equipped for success in the semiconductor industry.
Placement Guarantee by allowing students pay after placement
- Evolution of VLSI
- VLSI Design flow cycle
- Semiconductor Eco-system
- What is ASIC & FPGA
- FPGA design flow & ASIC design and verification flow
- SoC architecture
- SoC Design flow
- Opportunities for VLSI engineers in India
- VLSI industry work profiles and roles
- How to be industry ready?
- Number system introduction & radix conversion
- Complements of number systems
- Basics/complex gates operation & truth table
- NAND & NOR realization
- Boolean function implementation & optimization
- Multiplexer realization
- Introduction to sequential circuits (flip-flops & latches)
- Master–slave combination & its limitations
- Edge/level triggering & its advantages/disadvantages
- Synchronous & asynchronous circuits
- Frequency divider circuit
- Basics of N-Type & P-Type semiconductor.
- PN Junction Operation.
- Basics of MOSFET (PMOS/NMOS) ,CMOS & FinFet.
- Realization of Gates using MOSFET.
- Understanding of basics CMOS operation.
- CMOS Short Channel Effect , CMOS Leakage Current, DIBL effect.
- MOSFET Power consumption & Drain Current equation.
- Transistor Skewing & its effect.
- CMOS Fabrication Steps.
- Realization of D-Flip Flop using Transmission Gate.
- Linux Commands
- How to work with Gvim Editor Tool
- Shortcuts & Tricks
- Introduction - Why verilog, Language Concepts, and abstraction levels
- What is DUT and TB How to use Questa Sim and see the waveform and netlist
- Verilog Module and Dataflow Modelling
- DataTypes - whitespaces, comments, Strings, Numbers, Net, Reg, Vectors, Integer, Real, Time, Arrays
- Operators (Intro and Concatenation, Shift, Relational, Equality, Conditional, Arithmatic)
- Operators (Logical, Bitwise, Reduction)
- System Tasks and Compiler directives
- Gate Level Modeling (ALL gates and one circuit)
- Switch level (NAND)
- Structural Modeling (FA and MUX and mux from decoder and tristate buffers)
- Behavioural Modeling - Blocking vs Non-Blocking, if-else and Case and Loops
- Behavioural Modeling - All Flipflops
- Behavioural Modeling - Registers
- Behavioural Modeling - Counters, FSM Design
- What is Physical Design ?
- Physical Design Flow
- Inputs required for Physical Design
- Introduction to STA
- STA Flow & Integration
- STA Concepts & Terminologies
- Timing Parameters
- Slack Calculations
- Clock Skew
- Constraints in STA
- Design Rule Violations (DRV)
- Timing Reports
- Timing Arcs & Types
- Understanding Industrial Design Flow
- Inputs of Synthesis
- Logical aware & Physical aware Synthesis
- Synthesis Flow
- Synthesis optimization Techniques
- Advantages & Disadvantages of Synthesis
- Outputs of Synthesis
- Introduction to Sanity Checks
- Types Of Sanity Checks
- Introduction to Floor Plan
- Inputs of Floor Planning
- Creating Core & Die
- Shape & Size of the Block (Aspect Ratio)
- Macro Placement & Guidelines
- Ports & Pads Placement
- Blockages & Types
- Physical only cells placement
- Checks & Outputs
- Introduction to Power Planning
- Types of Power Consumptions
- PDN
- IR Drop Analysis & Fixes
- Electro Migration Causes & Fixes
- Methods of Power Planning
- Contents in UPF
- Power Optimization Techniques
- Checks & Outputs of Power Plan
- Introduction to Placement
- Inputs of Placement
- Timing driven & Congestion driven Placement
- Stages in Placement
- Reason for Congestion & Fixes
- Reason for Timing Failure & Fixes
- Fixes for DRV's
- Bounds & Types
- Path grouping
- Magnet Placement
- Checks & Outputs of Placement
- Introduction to CTS
- Inputs of CTS
- CTS Flow
- CTS Exceptions & Clock Tree Methodology
- Latency & Skew optimization
- CTS optimization Techniques
- NDR's
- Clock Routing Methodology
- Checks & Outputs of CTS
- Introduction to Routing
- Inputs of Routing
- Routing Flow
- Routing optimization Techniques
- Stages of Routing
- Routing Switches
- Routing Algorithms
- Checks & Outputs of Routing
- Introduction to Sign-Off
- Signal Integrity & Cross Talk Analysis
- Fixes of Cross Talk
- Antenna Violation & Fixes
- ECO Flows
- Introduction to Physical Verification
- LVS Checks
- ERC
- DRC
- DFM
- Low Power Checks
- Goals & Outputs of Physical Verification
- Timing Exceptions
- Uncertainity
- MMMC Analysis
- External Timing Concepts
- Special Timing Paths
- PBA & GBA Analysis
- Slack Calculations with uncertainity
- Derates
- Unateness
- Introduction to TCL
- TCL operators
- TCL control statements (if-else, while, for, foreach)
- TCL strings & their applications
- TCL lists
- TCL arrays
- TCL file handling operations
- TCL regular expressions
- TCL procedures
- TCL program examples & practice session
Trainees will work on industry-standard RTL-to-GDSII projects focused on optimizing for minimum area, low power, and high performance. Each project simulates real-world block-level physical design, requiring candidates to deliver a clean, sign-off-ready GDSII from the given input database.
- Creating a Unique Resume: Learn strategies to design a resume that reflects your individuality and aligns with industry expectations.
- Highlighting Technical Skills: Identify and list the most relevant technical skills that add value to your profile.
- Project Descriptions & Roles: Master the art of describing your projects, roles, and responsibilities effectively to demonstrate real-world experience and measurable impact.
- Mock Interviews & Practice Sessions: Participate in simulated interviews that mirror real industry scenarios.
- Interview Practice with Industry Experts: Gain insights and guidance directly from professionals working in your target domain.
- Personalized Feedback: Receive constructive feedback on your performance to help you improve and excel in future interviews.
