VLSI (Very Large Scale Integration) RTL (Register Transfer Level) Design and Verification is the process of designing and verifying the functionality of the digital circuits. This process involves implementing circuits using hardware description languages (HDLs) like Verilog or VHDL. RTL Design involves creating a high-level behavioral description of the digital circuit that specifies its functionality, and then translating this description into a register transfer level (RTL) description. The RTL description is a low-level representation of the circuit that specifies the behavior of each individual gate and the connections between them. The RTL description is then used to synthesize the circuit into a gate-level netlist, which can be used to implement the design in hardware.
Students will work on some of the below Design and Verification projects as part of training project. APB, AHB, AXI, SPI , UART, I2C, MEMORY CONTTROLLER, USB, UTMI, PCIE, ETHERNET, AES. Linux Operation System, Vim Editor.
